Products > Rapid PCB Prototyping > Circuit Board Plotters > Accessories > Dust Extraction Dust ExtractionIn order to effectively maintain the principle of the milling depth limiter, milling and drilling dust must be removed from the work area. The dust extraction system ensures a particularly reliable removal of the resulting dust. This extractor is equipped with a HEPA absolute filter to purify the exhaust air from any dust particles.The LPKF dust extraction system, designed especially for the LPKF ProtoMat S63 and ProConduct, features software control and automated switching when not in use. Technical Data: Dust extraction 241 m³/ hour (142 cfm) 320 m³/ hour (188 cfm) 800 W (230 V) or 960 W (120 V) 1.6 kW (230 V, 50/ 60 Hz) 250 x 300 x 350 mm(10'' x 12'' x 14'') 365 x 740 x 501 mm(14'' x 29'' x 20'') Approx. 65 dB (A) All specifications are subject to technical modifications. Rapid Prototyping Product CatalogView onlinePDF download

Here you will find the equipment necessary for ProConduct, ProMask and ProLegend processes. Handy measurement microscope for checking the machine parameters, Equipped with metric graticule and LED-light LPKF UV Light unit UV light unit for use during the ProMask and ProLegend process LPKF Hot Air Ovenruwac explosion proof vacuum cleaners Hot Air Oven for use during the ProConduct, ProMask and ProLegend processessamsung vivid canister vacuum cleaner LPKF Desktop Vacuum Tablecn4 vacuum cleaner bags Desktop Vacuum Table for use during the ProConduct process LPKF Vacuum Cleaner S Vacuum cleaner for the use of the Desktop Vacuum table during the ProConduct process

LPKF Set (5) filter bags for vacuum cleaner S Set (5) filter bags for vacuum cleaner S LPKF HEPA filter for vacuum cleaner S HEPA filter for vacuum cleaner S LPKF Set (2) carbon brushes for vacuum cleaner S Set (2) carbon brushes for vacuum cleaner S Desktop mode Mobile mode The best shopping cart software by ShopFactory powers D379. All-in one eCommerce software and shopping cart. NEW: Makes in house through-hole metallisation possible finally. Fast and simple process, without corrosive chemicals. This system makes use of a safe, special solder paste. click here for the digital brochure LPKF ProConduct Start set Contents of the start set: 20 x Protection Film Surface Foil 10 x Filter Fleece 20 x Paste per 2,5g 5 x Base material FR4 18/18 µm 5 x Base material FR4 35/35 µm 1 x Pressure roller 1 x PCB cleaning pad 1 x ProConduct Cleaner 1 x Laboratory gloves (100 pack) 1 x Gloves with reinforced inside

For the correct processing we advise: Desktop Vacuum table, item nr. Reflow Oven, item nr. LPKF Vacuum cleaner, item nr. LPKF ProConduct Paste Set Refill set consisting of: 20 Sachets of 2,5 gram ProConduct paste LPKF ProConduct Foil Set 20 x Protection Film Foil 10 x Filter fleece 10 x Cover foil Cleaner for ProConduct and ProMask For the removal of oxidation Hot Air Oven for use during the ProConduct, ProMask and ProLegend processesYou are here: Products > PCB Prototyping > Through-hole plating and multilayer solutions > ProConduct Revolutionary technology to produce plated through-holes, which does not require a plating tank or potentially hazardous processing chemicals. The LPKF ProConduct® through-hole conductivity system creates new technology for producing conductive through-holes without chemical electroplating tanks or potentially hazardous chemical processing. The LPKF ProConduct® system is an ideal solution for many in-house rapid PCB prototyping environments.

ProConduct® is perfect for low volume production, laboratories or shops where chemical electroplating is impractical, or any circumstance requiring an economical through-hole conductivity solution. Thanks to a parallel process even boards with high hole count are possible. LPKF ProConduct® uses a specially-developed conductive polymer to quickly and easily plate vias in just a few minutes. This four-stop easy-to-learn process lends itself well to parallel processing and results in smoothly plated through-holes in a fraction of the time and cost of chemical electroplating. The LPKF ProConduct® system plates vias as small as 0.4mm (15mil) up to an aspect ratio of 1:4. Smaller holes are possible under special conditions. The basic process requires only a few minutes for double-sided and even multilayer boards. The electrical resistance of LPKF ProConduct® results in extremely low – approximately 19.2 mΩ, depending on the material thickness. Key to in-house work When combined with LPKF ProtoMat circuit board plotter, the LPKF ProConduct® system becomes a key component to an in-house rapid PCB prototyping solution, featuring security, flexibility, and speed.

1. Mill the board with a LPKF circuit board plotter. 2. Apply special adhesive film to the surface of a milled PCB and drill the through-holes. Applying the protective film 3. Apply the conductive polymer to the PCB to fill the through-holes, then use the vacuum table to remove the excess conductor. Using the squeegee to apply the conductor 4. Remove the film cure the treated PCB in an oven for about thirty minutes. Curing the polymer in a hot-air oven 229 mm x 305 mm (9" x 12") 0.4 mm (15 mil) up to an aspect ratio of 1:4 Number of Plated Holes Reflow soldering 250 °C (482 °F), manual soldering 380 °C (716 °F) FR4, RF- and microwave materials (incl. PTFE-based materials) Average 19.2 mΩ with standared deviation of 7.7 mΩ Which system is best for you?Система пылеудаленияДля обеспечения работы ограничителя глубины фрезерования необходимо устранять на рабочем месте пыль и мелкую стружку, возникающие при фрезеровке и сверлении.
